| GENERAL |
|
| Length with standard bucket: |
106 in (269.2 cm) |
| Length without standard bucket: |
84 in (213.4 cm) |
| Width with standard bucket (7 in [17.8 cm] tracks): |
42 in (106.7 cm) |
| Width without standard bucket (7 in [17.8 cm] tracks): |
36 in (91.4 cm) |
| Width with standard bucket (9 in [22.8 cm] tracks): |
42 in (106.7 cm) |
| Width without standard bucket (9 in [22.8 cm] tracks): |
40 in (101.6 cm) |
| Height: |
58 in (147.3 cm) |
| Height (to hinge pin): |
85.5 in (217.7 cm) |
| Ground clearance: |
6 in (15.2 cm) |
| Bucket rollback at ground level standard bucket: |
33° |
| Dump angle at max pin height standard bucket: |
26° |
| Reach of standard bucket at full height: |
22.87 in (58.1 cm) |
| Weight with standard bucket (9 in [22.8 cm] tracks): |
3,595 lb (1,630.7 kg) |
| Weight with no bucket, (9 in [22.8 cm] tracks, diesel engine): |
3,350lb (1,519.5 kg) |
|
|
| ENGINE OPTION TWO (INTERNATIONAL ONLY) |
|
| Make and model: |
Kubota V1505 |
| Fuel type: |
Diesel |
| Fuel tank capacity: |
13 gal (49.2 L) |
| Gross horsepower: |
35 hp (26.1 kW) |
| Max engine torque: |
68 ft-lb (47.6 Nm) |
| Cooling system: |
Liquid |
| Max angle of inclination: |
30° |
| Hydraulic system flow: |
15.5 gpm (58.7 L/min) |
|
|
| TRACK PERFORMANCE |
|
| Rated operating capacity (SAE): |
925 lb (419.6 kg) |
| Tipping capacity (with 165 lb [74.84 kg] operator): |
2,643 lb (1, 198.9 kg) |
| Travel speed (fwd/rev): |
25 hp (18.6 kW) – 4.1 mph (6.6 km/h)/35 hp (26.1 kW – 4. 5mph (7.3 km/h)/3.0 mph (4.8 km/h) |
| Ground pressure (7 in [17.8 cm] tracks/9 in [22.8 cm] tracks): |
5 psi/4 psi (.4 bar/ .3 bar) |
|
|
| OPERATIONAL |
|
| Steering: |
Dual axis, pilot-operated joystick |
| Lift: |
Dual axis, common bucket lever |
| Curl: |
Dual axis, common bucket lever |
|
|
